Construction telehandlers

RS8-42 GEN:4

Construction telehandlers

The RS8-42 GEN:3 is ready to power through your work day with 42' reach 8,000lb lift capcity. The unmatched visibility allows for you to stay safe on the jobsite, which is always our utmost priority. The industry-exclusive boom tip lift hook allows for the versatility you crave out of your work partner. Get in a GEHL Telehandler today and see what you've been missing.

See more See less
Ask for a quote Find a dealer
8000 lb
42 ft
28 ft 3 in
120 Hp
Learn more about the GEHL warranty

Technical features

Capacities

Max. capacity

8000 lb

Max. lifting height

42 ft

Max. outreach

28 ft 3 in

Weight and dimensions

Length to face of forks

19 ft

Overall width

7 ft 10 in

Overall height

7 ft 10 in

Wheelbase

10 ft

Ground clearance

16 in

Overall cab width

33 in

External turning radius

13 ft 9 in

Unladen weight

23349 lb

Overall weight

23349 lb

Standard tyres

13x24

Frame levelling longitudinal +/-

10 °

Engine

Engine brand

Deutz

Engine norm

Stage IV

Engine model

TCD 3.6 L4

I.C. Engine power rating - Power (kW)

120 Hp / 89 kW

Max. torque / Engine rotation

354 ft/lbs @ 1600 rpm

Transmission

Transmission type

Powershift

Max. travel speed

20 mi/h

Parking brake

SAHR

Service brake

Wet disc brakes

Axle Manufacturer

Dana

Hydraulics

Hydraulic flow / Pressure

41 US gpm-3002 PSI

Tank capacities

Hydraulic oil

31 US gal

Fuel tank

47 US gal

Miscellaneous

Controls

Single joystick with FNR
