Compact Loaders

R190

Compact Loaders

Boasting 862 kg of rated operating capacity this machine is not to be underestimated. With the optional counterweight added this machine can lift over a ton! Remember to consider how you'll be transporting the machine you choose because a smaller body style may play to your advantage. Visit a dealer today to get behind the controls and find the right fit for you. On a farm or jobsite daily tasks change and this machine is suitable to be your multifunctional tool that fits every job perfectly.

See more See less
1900 lb
158 in
23 in
127 in
Learn more about the GEHL warranty

Gallery

Technical features

Capacities

Rated Operating Capacity

1900 lb

Rated Operating Capacity with Optional Counterweight

2110 lb

Unladen weight

6881 lb

Weight and dimensions

Overall Operating Height - Fully Raised

158 in

Height to Hinge Pin – Fully Raised

121 in

Overall Height to Top of ROPS

80 in

Dump angle at full height

42 °

Dump height

91 in

Overall length with bucket

127 in

Dump reach - Full height

23 in

Rollback at ground

26 °

Seat to ground height

39 in

Wheelbase

42 in

Overall width less bucket

64 in

Bucket Width

66 in

Ground clearance

6 in

Overall length - Less Bucket

94 in

Clearance Radius - Front with Bucket

79 in

Clearance Circle - Front without Bucket

44 in

Clearance Circle - Rear

59 in

Performances

Travel Speed with Two-Speed Option - Maximum

12 mi/h

Travel speed (unladen)

8 mi/h

Wheels

Standard tyres

10.00x16.5 HD

Engine

Engine brand

Yanmar

Engine model

4TNV98C-NMSLV Stage V

Engine norm

Stage V

Gross Power (kW)

69 Hp

Net Power (kW)

68 Hp

Max. torque / Engine rotation

178 ft/lbs / 1625 rpm

Battery

12 V

Starter (kW)

4 Hp

Hydraulics

Standard flow - Auxiliary hydraulics

18 US gpm

High-Flow Auxiliary Hydraulics – Option

31 US gpm

Tank capacities

Fuel tank

17 US gal

Reservoir Capacity Hydraulics

8 US gal

Displacement

0.87 US gal

Noise and vibration

Environmental noise (LwA)

101 dB

Whole-Body Vibration (ISO 2631-1)

0.96 m/s²

Vibration to whole hand/arm

< 1.50 m/s²
