Compact Loaders

VT230 - NEW

Compact Loaders

You got work to do? The VT230 gets it done. Balancing size with performance in an optimized package, the medium-frame VT230 vertical lift Track Loader is built to handle tough environments—like construction sites and lumber yards—in the worst conditions. In the rain, mud, or snow, it's ready to go. Featuring a spacious cab with improved visibility to help operators spot hazards and a simplified operator control station, this machine keeps you safe, confident, and prepared on the job site. Technicians will be ready for anything thanks to our new centralized maintenance point located near the rear of the machine which improves access and serviceability to help reduce maintenance labor. Strong, durable, and simple to maintain, the VT230 is built to work like you—getting the job done today, tomorrow, and every day after without complaining.

See more See less
2300 lb
159 in
36 in
141 in
Learn more about the GEHL warranty

Gallery

Technical features

Capacities

Rated Operating Capacity

2300 lb

Operating Capacity At 50% Tipping Load

3286 lb

Rated Operating Capacity with Optional Counterweight

2400 lb

Operating Weight

9251 lb

Unladen weight

8415 lb

Weight and dimensions

Operating Weight - Approximate

9251 lb

Overall Operating Height - Fully Raised

159 in

Height to Hinge Pin – Fully Raised

121 in

Overall Height to top of ROPS

81 in

Dump angle at full height

42 °

Dump height

91 in

Overall length with bucket

141 in

Dump reach - Full height

36 in

Rollback Angle at Full Height

92 °

Seat to ground height

38 in

Overall width less bucket

69 in

Ground clearance

8 in

Overall length - Less Bucket

110 in

Clearance Radius - Front with Bucket

88 in

Clearance Circle - Front without Bucket

54 in

Clearance Circle - Rear

64 in

Performances

Travel Speed with Two-Speed Option - Maximum

10 mph

Travel speed (unladen)

6 mph

Engine

Engine brand

Yanmar

Engine model

4TNV98CT-XNGL

Engine norm

Stage V, Tier 4

Gross Power

53.70 kW

Net Power

52.70 kW

Max. torque / Engine rotation

217 ft/lbs / 1800 rpm

Power source

Diesel

Number of cylinders

4

Engine cooling system

Water

Battery voltage

12 V

Alternator - Ampere

100 A

Starter

3 kW

Hydraulics

Standard flow - Auxiliary hydraulics

23 US gpm

Auxiliary Hydraulic Pressure

3475 PSI

High-Flow Auxiliary Hydraulics – Option

30 US gpm

High-Flow Auxiliary Hydraulics Pressure – Option

3325 PSI

Tank capacities

Fuel tank

39 US gal

Displacement

0.87 US gal

Coolant system capacity

5 US gal
